3.5 Ton Capacity Service Jack


Add to cart

Request a call


Click to view California Proposition 65 warning


The LDJ35 is a 3-1/2-ton capacity service jack that is ideal for both a large automotive service center or a one-person shop. Under load, the dual-stage hydraulic unit can reach maximum height in 7 pumps. An extra wide lifting range increases the versatility for shops. A padded spring-loaded handle rapidly returns after each pump, allowing techs to lift the vehicle faster with less effort. Heavy-duty rolled edge construction adds strength and resists twisting for increased safety. Cycle tested design for a long life of professional duty.



  • 3.5-ton capacity
  • Lifting range: 5.2" to 21.9"
  • Reach: 78.5"
  • Saddle: 6" dia., flat steel, rubberized, pinned to lifting arm
  • Frame height: 6.25"
  • Handle length: 50" spring-loaded padded lower handle
  • Floor space: 14.5" x 28.5"
  • Casters: 4; 3.15" front fixed (2), 2.5" rear swivel (2)
  • Limited Lifetime Warranty



Weight approx. 92 lbs
Dimensions (L x W x H) 28.5 x 14.5 x 6.25 inch
